9.4 MANUAL MENU

From the main menu, hold down simultaneously the "SET" and "+" and "-" keys until the MANUAL MENU page appears (or use the selection menu
pressing + or -). The menu allows you to view and modify various configuration parameters: the MODE key allows you to scroll through the menu pages,
the + and – keys allow you respectively to increase and decrease the value of the parameter concerned. Press SET to leave this menu and return to the
main menu. Entering the manual menu by pressing the SET + - keys puts the machine into forced STOP condition. This function can be used to force
the machine to stop. In the main menu, irrespective of the parameter displayed, it is always possible to perform the following controls:
Temporary starting of the electropump:
Pressing the MODE and + keys at the same time causes the pump to start at speed RI and this running status remains as long as the two keys are held
down. When the pump ON of pump OFF command is given, a communication appears on the display.
Starting the pump:
Holding down the MODE - + keys simultaneously for 2 sec. causes the pump to start at speed RI. The running status remains until the SET key is
pressed. The next time the SET key is pressed the pump leaves the manual menu. When the pump ON of pump OFF command is given, a
communication appears on the display. In case of operation in this mode for more than 5' with no flow of liquid, an alarm overheating alarm will be
triggered, with the error PH shown on the display. Once the PH error condition is no longer present, the alarm will be reset automatically only. The reset
time is 15'; if the PH error occurs more than 6 times consecutively, the reset time increases to 1h. Once it has reset further to this error, the pump will
remain in stop status until the user restarts it using the "MODE" "-" "+" keys.

Status

RI: Speed setting

VP: Pressure display

VF: Flow display

PO: Absorbed power display

C1: Phase current display

RS: Rotation speed display

TE: Dissipator temperature display

9.5 INSTALLER MENU

From the main menu, hold down simultaneously the "MODE" and "SET" and "-" keys until the first parameter of the INSTALLER MENU appears on the
display (or use the selection menu pressing + or -). The menu allows you to view and modify various configuration parameters: the MODE key allows you
to scroll through the menu pages, the + and – keys allow you respectively to increase and decrease the value of the parameter concerned. Press SET to
leave this menu and return to the main menu.
MANUAL MENU
Displays the pump status.
Sets the motor speed in rpm. Allows you to force the number of revolutions at a predetermined value.
Plant pressure measured in [bar] or [psi] depending on the measuring system used.
Displays the flow in the chosen unit of measure. The measuring unit may be [l/min] o [gal/min] vedi par. 9.5 - MS:
Measuring system.
Power absorbed by the electropump in [kW].
A flashing round symbol may appear under the symbol of the measured power PO. This symbol indicates the
pre-alarm for exceeding the allowed maximum power.
Motor phase current in [A].
A flashing round symbol may appear under the symbol of the phase current C1. This symbol indicates the pre-
alarm for exceeding the allowed maximum current. If it flashes at regular intervals it means that the motor overload
protection is about to trip and it will very probably go into protection status.
Motor rotation speed in rpm.
