_ Jacobs Keyed Drill Chuck 4.0mm/6.5mm
Order Code
Maximum Rotation Speed min
Chuck Capacity mm
Cannulation mm
Dimension of Attachment (ØD x L) mm
Applicable Cutting Accessories
_ AO Drill Chuck
Order Code
Maximum Rotation Speed min
Cannulation mm
Dimension of Attachment (ØD x L) mm
Applicable Cutting Accessories
_ Keyless Drill Chuck
Order Code
Maximum Rotation Speed min
Chuck Capacity mm
Cannulation mm
Dimension of Attachment (ØD x L) mm
Applicable Cutting Accessories
(ØD)
PD-DA-J4
1,200
-1
Ø0.5 - 4.0
Ø4.2
Ø21 x 93
Commercially available drill bit, wire or pin
with Ø4.0mm or less shank
(ØD)
PD-DA-A
1,200
-1
Ø1.5
Ø25 x 84
Commercially available AO-type drill bit
(ØD)
PD-DA-K
-1 1,200
Ø0.6 - 7.4
Ø4.2
Ø31.5 x 84
Commercially available drill bit, wire or pin with Ø7.4mm or less shank
(L)
PD-DA-J6
Ø0.5 - 6.5
Ø31 x 108
Commercially available drill bit, wire or pin
with Ø6.5mm or less shank
(L)
(L)
25
Product Description
