12 Appendix
Standard tolerances for shaft alignment
In the following, you see the standard tolerances for the alignment of industrial machines with flexible
coupling. Only use these tolerances, if there are no in-house guidelines or guidelines provided by the
shaft manufacturer. Do not exceed these tolerances.
RPM Good
Parallel
misalignment
Up to 1000 0,08
Up to 2000 0,06
Up to 3000 0,04
Up to 4000 0,03
More than 4000 0,02
Manual
Acceptable
Angular Parallel
misalignment misalignment
0,07 0,12
0,05 0,10
0,04 0,07
0,03 0,05
0,02 0,04
96
hierarchy (open folder)
Otherwise select a report in the view
dialog and save the report in the
save dialog.
If you do not wish/need to
change the storage medium,
there is an easy one-click
method to save reports as a
PDF:
Press first; the save-dialog
will appear. Press
save the report as a PDF-file. A
PDF subfolder is automatically
created and the report with the
same filename and .pdf-ending
is stored inside.
Angular
misalignment
0,10
0,08
0,07
0,05
0,04
again, to
