Introduction

Thank you for purchasing a Shaft alignment tool from PCE Instruments.
With the help of a Shaft alignment tool, you can perform shaft alignment on machines and motors quickly
and easily. For this purpose, the Shaft alignment tool possesses two special laser sensors, which are
fixed to the particular shaft. The Shaft alignment tool directly displays the corresponding correction values
for every machine base after a short measurement time. In addition to special programs for the alignment
of machines and motors, you can perform further geometrical measurements with the PCE-TU 3.
2

Safety notes

Please read this manual carefully and completely before you use the device for the first time. The device
may only be used by qualified personnel and repaired by PCE Instruments personnel. There is no
warranty of damages or injuries caused by non-observance of the manual.
This manual is published from PCE Instruments without any guarantee.
We expressly point to our general guarantee terms, they can be found in our general terms of business.
If you have any questions please contact PCE Instruments.
2.1

Precautions

The PCE-TU 3 is a class II laser system with a typical wavelength of 670 nm, < 1MW capacity and a
maximal radiation energy of 0,1 mJ per impulse. The class II laser meets the requirements according to
ANSI, BS 4803, IEC 825 and the US American FDA. Note the following safety notes to avoid injury and
damages on the device.
Caution:
- Do not ever directly look into the laser beam!
Do not ever directly point the laser beam into anyone's eyes!
-
Warning!
Make sure that the machines you measure are not started by accident, because injuries might occur. To
avoid that risk, you should either block the power switch in the OFF position or remove the corresponding
fuses. These security measures need to be maintained until the measuring system is removed from the
machines.
Disclaimer
Neither PCE Instruments, nor authorised salesmen can be blamed for damages on machines or working
tools that might occur in the process of working with the PCE-TU 3 system. We check the manual
carefully, to avoid possible errors. If you find an error in this manual, we would be very grateful, if you let
us know.
