Straightness Program

8.3.1

Short explanation

The Straightness Program is applied to determine the straightness of objects. Very long objects can be
measured in parts (Splices). The measurement of vertical objects is possible as well.
8.3.2

Carry out a straightness measurement

To start the program, select "Straightness" in the main menu under the sub item "Geometry" and press
. The main screen will appear.
8.3.3

Main screen of the program (configure positions and change parameters)

What should be noted in this window
The required dimensions should be entered
correctly (can be changed later on, if
recommended, measurement data will not
be influenced).
Functions in this screen
- Create/modify/view point
- Create/modify/view Part (Splice)
- Change parameter
- Enter dimensions
- Start measurement
- View misalignment results (available, after
all required measurements have been
carried out
- Save
- Load
Manual
Shortcuts in this window
Start a new measurement
Enter number of measurement points
(positions)
Equal or delete all distances
Enter current distance
Enter number of the parts (splices) –
(optional). When using splices, this
button adds a new part.
Change parameters (manual data entry
or for the sensor; manual angle entry or
for the inclinator ; filter settings.
View results (available, if all required
measurements have been carried out)
Save results to a file (see chapter 10
"Handling of the Data Dialogue
window")
Load saved results from a file (see
chapter 10 "Handling of the Data
Dialogue window")
Select point to enter distance
