Live Mode
To carry out live alignment for the selected plane, place the detector in the centre of the bore. The
clamping device should be fixed to the bottom side of the bore, inclined at 180°.
Switch from the reference line mode to the result mode and the table illustration. Select the required
plane due to
and
be activated.
If the manual angle entry is activated, enter the corresponding value.
Press
again, to start the Live Mode.
Do not move any components until "LIVE MODE" appears on the screen.
Move the component towards zero with the help of the measurement values on the screen. To stop the
Live Mode and to receive the result after the movement, press
Do not stop the Live Mode, if the measurement values are not ready (laser beam is out of aim, sand
glass symbol or connection problems)
Manual
and press
to receive the measurement screen, where the Live Mode can
Live Mode is ready,
but not started yet
Live results, move
towards zero
After the Live Mode was stopped, a plane can be selected.
Select a new plane, place the detector in the centre of the
bore, press
selected plane.
The alignment of a plane can influence other planes. Repeat
the measurement after using the Live Mode (go to the result
screen and press
[*] means that the
plane has been set in
Live Mode
.
and then
,to start the Live Mode for the
to repeat the measurement).
73
Live Mode
activated, start
alignment
