Change/Add Parameters - PCE Instruments PCE-TU 3 Bedienungsanleitung

Measurement
unit
Distance sensor S – middle of the
coupling
Distance sensor S – sensor M
sensor S – edge of the
machine (F1)
Distance of the middle of the
bolt on the flange (average)
7.2.2

Change/add parameters

What should be noticed in this window
Use the Biaxial Live function with stable shaft
positions, because the smallest rotations can
lead to errors
Functions in this screen
- Manual entry or use of the sensor data
- Selection between 2 or 3 decimal digits
- Selection of the measurement unit (mm/inch)
- Alignment to the X- and Y-coordinates
simultaneously or just to the Y-coordinates
(default)
Manual
Shortcuts in this window
30
Amount of bolts
Activate/deactivate manual data
entry
Selection between 2 or 3 decimal
digits
Selection of the measurement
unit (mm/inch)
Activate/deactivate Biaxial Live
Alignment
Save and exit
