Stryker M-1 Roll-In System Bedienungsanleitung Seite 11

Wheel diameter/ width (6100-031-000 and 6100-
033-000)
Handle extension (6100-031-000 and 6100-033-
000)
Caster diameter/width (6100-003-000)
Shock position (6100-031-000)
Knee gatch position (6100-031-000)
Minimum operators required for loading/
unloading
Recommended fastener systems
Recommended floor/tray height
1 Height is measured from bottom of mattress at seat section to ground level.
2 Standard base unit is weighed without optional accessories.
Stryker reserves the right to change specifications without notice.
T T h h e e y y e e l l l l o o w w a a n n d d b b l l a a c c k k c c o o l l o o r r s s c c h h e e m m e e i i s s a a p p r r o o p p r r i i e e t t a a r r y y t t r r a a d d e e m m a a r r k k o o f f S S t t r r y y k k e e r r C C o o r r p p o o r r a a t t i i o o n n . .
6100-109-005 Rev C.1
4.0 in. / 0.8 in.
7.75 in.
6 in. / 2 in.
+17°
30°
1
Model 638 1 Floor Mounted - Center Mount, Straight
Guide
Model 6373 Tray Mounted - Center Mount, DIN
Guide
Model 6376 Floor Mounted - Center Mount, Straight
Guide - No side restraints
27 in. - 31 in.
10.2 cm / 2.0 cm
19.7 cm
15.2 cm / 5.1 cm
68.6 cm - 78.7 cm
7 EN
