Accessories
• Docking Station.
• Non intelligent instrument holder with duplicated instrument connectors.
• User can either plug cables directly into instrument or docking station.
• Ability to pick instrument up and walk away without unplugging cables.
• Provides extra desktop stability.
• Docking station holds 3M Clean-Trace NG Luminometer at optimum working/viewing angle for desktop use.
• Carry pouch.
• 3M™ Clean-Trace™ Biomass Detection Kit Cuvette Holder (Hold-Tite) – required when test conducted using cuvettes e.g.
In the Biomass Detection Kit.
Dimensions • Approx 205mm x 85mm x 60mm.
Weight • 400 grams.
• Storage Range 4°C - 40°C.
temperature • Optimum Operating Range 15°C - 25°C.
• Built in temperature sensors.
• Li-Ion.
Battery • Do not incinerate.
• Non hazardous.
10.02 Terms and Conventions
the following conventions are used to represent certain items and actions throughout this manual:
Bold capitals
Bold lower case
single quote
A list of possible functions displayed on the screen where each function may be selected using the cursor leys and
Menu
function buttons.
RS232 A method of connecting to the Pc. A specific cable connector is required.
A sample plan is a list of test points with pass and fail levels previously generated using 3M clean-trace Data trending
Sample plan
software on the Pc.
Self check A means of checking that the instrument is operating within set performance limits.
USb
A method of connecting to the Pc. A specific cable connector is required.
e.g. Date Format
e.g. Select
e.g. 'Month'
A menu item
A key press using one of the function buttons
A specific item within a menu
