rs232 Power from charger
usB (V2 only)
to use, simply locate the 3M clean-trace nG Luminometer into the aperture and apply light downward pressure. the connectors to the printer, Pc and
charger can be left permanently in place if required.
3.02 The Printer
3M discontinued sales of the optional 3M Printer in 2011 due to lack of demand for this accessory. An alternative method for printing results is to use
the reports feature in the 3M clean-trace Data trending software. refer to the 3M™ clean-trace™ Data tracking software Quickstart Guide for
more information.
3.03 Carry Pouch
the 3M clean-trace nG Luminometer is a light-weight, fully portable instrument for use in production areas and laboratories and can be supplied with
an optional carry pouch for added mobility and protection. the instrument may be removed from the carry pouch when taking measurements but also
possible to perform a measure with instrument still in its pouch. samples may be inserted after folding back the flap at the top of the carry pouch. to
prevent the 3M clean-trace nG Luminometer being dropped there is a lanyard attached to the pouch which fixes onto the instrument.
the illustration above shows a convenient method of use. Adjust the straps for the correct height and degree of security.
Important Note:
care should be taken to ensure the strap does not get trapped when operating near heavy machinery to avoid possible injury.
