CHLORIDE LINEAR Plus/RM
7 ESD Contacts (control)
7a ESD Contacts, hardwired
8 UPS interface COM 3
9 Battery socket
10 Strain relief
11 Mains connection, Terminal Block
12 Battery socket for battery connection cable to UPS
13 Battery extension cable socket. Connected to UPS or another battery
extension
14 Option battery socket for connect to a UPS 6 kVA
15 Earth connection
16 Battery extension connection cable
17 S1, S2: Paralleling terminals (bridged 10 mm
block mode, open if UPS in parallel operation)
18 Terminals for backfeed control
Note
Each battery extension Rackmount BP 10kVA is supplied with one
battery connection cable (16). The first extension is connected to the
battery connection cable of the UPS (10), each subsequent extension is
connected by means of the battery extension connection cables (16).
The cables are designed to be non-interchangeable, because the sockets
(13) are coded.
Connecting Power Cables Linear PLus 60 and Linear
PLus 100
Open UPS input breaker
Open UPS output breaker
Set maintenance switch to position BPS (Bypass)
Remove terminal area safety cover
Connect loads to "Output" terminals
Connect mains to the corresponding input terminals ( "Terminals
Linear Plus 6 kVA" on page EN-24 and "Rear View Linear Plus 10 kVA"
on page EN-25).
User Handbook SU59802UM01, rev.3/ Last modified: 08/2005
Installation
2
if UPS works in single
E
N
EN-27
