Chloride Linear Plus RM Benutzerhandbuch Seite 20

Installation
UPS-TYPE
Electrical Data
Rating
Input
Battery
external
Output
General
Overvoltage category
Protection class
Cooling
1)
Table 5: Electrical data Linear Plus RM 6 kVA/10 kVA
UPS-TYPE
Mechanical Data
UPS
Unit dimensions
EN-18
Voltage
Frequency
Current
1)
Type
Voltage/Ah
Type
Voltage
Frequency with mains control
Frequency with internal clock
Nominal current at
cos ϕ = 0.7 and 230 V
use battery type for replacement purpose also. No other type permitted
Weight / kg
Dimensions / mm
Width
Height
Depth
Linear Plus RM 6 kVA Linear Plus RM 10 kVA
6 kVA
27 A
External battery packs
only (1 to 3 packs)
240V/ 20x(12V/ 5Ah)
26 A
Linear Plus RM 6 kVA Linear Plus RM 10 kVA
17 .5
650
User Handbook
CHLORIDE LINEAR Plus/RM
1N/AC 220,230,240V
50/60Hz ± 5%,
automatic frequency sensing
External battery packs
only (1 to 4 packs)
240V/ 20x(12V/7Ah)
Yuasa Rew 45-12-7Ah
1N AC 220,230,240V ± 2%
see input frequency
50/60Hz ± 0.5%
II
IP 20
Ventilator
482.6
130
SU59802UM01, rev.3/ Last modified: 08/2005
10 kVA
45 A
43.5 A
24.5
715
