5.5 USE IN RECIPROCATING MODE

Once the parameters have been set:
1. Fit an instrument (file) to the contra-angle.
2. Check the integrity of the device and its accessories before use in order to detect any problem. Do not use the device if it appears to
be damaged or faulty.
3. Press the footswitch (Fig. 4.4).
4. The motor starts running.
5. Use the same note (5.3) and observe precautions than those descibed in rotating mode.

5.6. ULTRASONIC MODE SETTING

Before operating the unit:
1. Select "Ultrasonic" using the MODE key or the multifunctional footswitch (Fig. 4.1).
2. Sterilize the handpiece, the Sterijoint (if used) and tips (see section "Sterilization").
3. Select the appropriate tip, and connect it by screwing it on with the supplied wrench. Tighten it moderately (see Fig. 6 below).
Fig. 6 Tip tightening with wrench
4. Make sure there is no trace of moisture in the handpiece connection, if this is the case then wipe it and dry it with the air blower.
Then connect the handpiece carefully to the handpiece connection without twisting or rotating. If irrigation is needed, connect the
Sterijoint in between the handpiece and its cord.
Warning
 Neither rotate the handpiece nor twist the handpiece connector on its cord.
 Correct tip vibration requires a tight fit, but without over-tightening it. Over-tightening the tip with force may damage tip and/or
handpiece.
 Do not rotate the handpiece during installation of the tip when the handpiece is already connected to the cord.
Program:
The program preset is as following:
- Power range: Soft
- Setting: 3
- Pump: 2
ULTRASONIC
Power range:
Setting:
The first row shows the:
 MODE
The second row shows the:
 Power range
The third row shows the:
 The power setting
The fourth row shows the:
 Flow rate
Soft
3
Pump: 2
14
