6. How to Acquire CBCT Images
Double Scan Mode
6.3.2
For the double scan mode. The system scans the maxilla and mandible. For this
reason, the patient needs to position for each scan.
First Scan (Mandible Scan)
Follow the steps below to position the patient.
Remove all metal objects that the patient wears.
1.
Ask the patient to wear a lead apron. If necessary, help the patient to put on
2.
the apron.
Use the column up/down button to adjust the column's height for the patient.
3.
98
DO NOT invite the patient to the X-ray room until the
equipment stops moving.
For the CBCT mode, you cannot change the horizontal
beam's position.
Metal objects can cause ghosts or shadows
on the X-ray image and lower the image
quality.
Ensure that the patient does not collide with
the equipment while in motion.
