Normal CBCT
6.2.1
Follow the steps below to set exposure settings for a normal CBCT capture.
Select a FOV. Once selected, the system set the vertical and horizontal option
1.
according to the selected FOV.
The table below shows matching vertical and horizontal options with each
FOV.
Green X 12 TM (Model: PHT-75CHS) User Manual
FOV Vertical Option
Occlusion
12x8.5 TMJ
SINUS
8x8 Occlusion
Maxilla
8x5
Mandible
To capture a TMJ or Sinus image, select 12x8.5 from the
FOV menu.
6. How to Acquire CBCT Images
Horizontal Option
Center
Right
Left
Center
Right
Center
Left
Right
Center
Left
Right
Center
Left
