Sinus Mode (LAT / PA)
4.3.3
Follow the steps below to position the patient.
Remove all metal objects that the patient wears.
1.
Ask the patient to wear a lead apron. If necessary, help the patient to put on
2.
the apron.
Use the column up/down button to adjust the column's height for the patient.
3.
Ask the patient to enter the equipment and give the following instructions:
4.
▪
▪
▪
Ask the patient to press the acanthion point against the chinrest and tilt
5.
forward at 5 ˚. Ensure that his or her jaw does not touch the equipment.
Green X 12 TM (Model: PHT-75CHS) User Manual
Metal objects can cause ghosts or shadows on
the X-ray image and lower the image quality.
Stand straight.
Grab handles with both hands.
Place the chin on the chinrest.
4. How to Acquire PANO Images
