6. How to Acquire CBCT Images
Select an Image Option.
3.
Select a patient type.
4.
Select an X-ray intensity level.
5.
90
Mode
High Resolution
Green Normal-Resolution image
Patient
Man
Woman
Child
Average head
Category
circumference (cm)
Child
(Age 12 or
under)
Adult
(Above Age
12)
Description
High-Resolution image
VATECH standard
Males over the age of 12
Females over the age of 12
Male or Female under the age of 12
Range (cm)
53±3
56±3
Green X 12 (Model: PHT-75CHS) User Manual
TM
Intensity level
>53±3 Hard
53±3 Normal
<53±3 Soft
>56±3 Hard
56±3 Normal
<56±3 Soft
