Ask the patient to press his or her acanthion point against the special bite A
6.
and tilt the head forward at 5˚. Ensure that the patient's jaw does not touch
the equipment.
Adjust the patient's position according to the laser beam's location.
7.
The vertical beam must be aligned with the patient's mid-sagittal
▪
plane. If necessary, center the patient's head.
▪ The horizontal beam must be aligned with the patient's Frankfurt
plane. Use the beam up/down button to change the beam's location.
Ask the patient to open his or her mouth and close eyes.
8.
Use the temple supports knob to close the temple supports to secure the
9.
patient's head.
10. Leave the X-ray room and follow the instructions in 4.4 Acquiring Images.
Green X 12 TM (Model: PHT-75CHS) User Manual
4. How to Acquire PANO Images
To prevent vision loss, ensure that the
patient's eyes do not meet the laser beam
during positioning.
Review the patient's position before leaving
the X-ray room. If necessary, reposition the
patient.
