6. How to Acquire CBCT Images
Guide the patient to the X-ray room when you see the message below.
9.
10. Position the patient following 6.3.1 Other Capture Modes. Then follow the
steps in 6.4 Acquiring Images.
11. [Image Selection] After taking the X-ray select the areas for image
reconstruction. The selection can be made up of three.
12. Click Complete. The system will start image reconstruction.
88
DO NOT click Confirm unless your selections
are final. You cannot change exposure
settings after clicking the button.
When the progress bar reaches 100%, the
Confirm button turns into the Ready button.
DO NOT click Complete unless your selections
are final. You cannot change settings after the
button is clicked.
Green X 12 (Model: PHT-75CHS) User Manual
