4. How to Acquire PANO Images
The exposure condition is selected after you chose the X-ray intensity level. To
4.
change the condition, click the plus-minus button next to the voltage and the
current symbols.
Each time you click the button, the voltage value changes by ±1.0 kVp, and
the current value by ±1.0 mA.
The table below shows the range of exposure conditions you can adjust.
Click Confirm. After clicking the button:
5.
▪
▪
▪
▪
Guide the patient to the X-ray room when you see the message below.
6.
48
Minimum Value
Mode
kVp
PANO 60
The rotating unit moves to the scanning position.
Laser beams are turned on.
The progress bar appears above the Confirm button.
The scan information window shows the estimated DAP (Dose Area
Product), scan time, and exposure time.
Maximum Value
mA kVp
4 90
DO NOT click Confirm unless your selections
are final. You cannot change exposure
settings after clicking the button.
When the progress bar reaches 100%, the
Confirm button turns into the Ready button.
