Select an area to capture an image.
3.
Once the X-ray intensity level is selected, the system automatically sets the
4.
exposure condition. To change the condition. Click the plus-minus button next
to the voltage and the current symbols.
Each time you click the button, the voltage value changes by ± 1.0 kVp, and
the current value by ± 0.1 mA.
The table below shows the range of exposure conditions that you can adjust.
Mode
Model
Click Confirm. After clicking the button.
5.
▪
▪
▪
Follow 7.2 Model Positioning.
6.
Green X 12 TM (Model: PHT-75CHS) User Manual
Minimum Value
kVp
60
The rotating unit moves to the scanning position.
The vertical beam is turned on.
The scan information window shows the estimated DAP (Dose Area
Product), scan time, and exposure time.
7. How to Acquire 3D Model Scan Images
Maximum Value
mA kVp
4 99
kVp
12
