6. How to Acquire CBCT Images
Select a patient type.
5.
Select an X-ray intensity level.
6.
Once the X-ray intensity level is selected, the system automatically sets the
7.
exposure condition. To change the condition. Click the plus-minus button
next to the voltage and the current symbols.
Each time you click the button, the voltage value changes by ± 1.0 kVp, and
the current value by ± 0.1 mA.
The table below shows the range of exposure conditions that you can adjust.
84
Patient
Man
Woman
Child
Average head
Category
circumference (cm)
Child
(Age 12 or
under)
Adult
(Above Age
12)
Minimum Value
Mode
kVp
CBCT 60
VATECH standard
Males over the age of 12
Females over the age of 12
Male or Female under the age of 12
Range (cm)
>53±3
53±3
<53±3
>56±3
56±3
<56±3
mA kVp
4
Green X 12 (Model: PHT-75CHS) User Manual
TM
Intensity level
Hard
53±3 Normal
Soft
Hard
56±3 Normal
Soft
Maximum Value
kVp
99 14
