Once the X-ray intensity level is selected, the system automatically sets the
6.
exposure condition. To change the condition. Click the plus-minus button next
to the voltage and the current symbols.
Each time you click the button, the voltage value changes by ± 1.0 kVp, and
the current value by ± 0.1 mA.
The table below shows the range of exposure conditions that you can adjust.
Mode
CBCT
Click Confirm. After clicking the button:
7.
▪ The rotating unit moves to the scanning position.
▪ Laser beams are turned on.
▪ The progress bar appears above the Confirm button.
▪ The scan information window shows the estimated DAP (Dose Area
Product), scan time, and exposure time.
Green X 12 TM (Model: PHT-75CHS) User Manual
6. How to Acquire CBCT Images
Minimum Value
kVp mA
60 4
DO NOT click Confirm unless your selections
are final. You cannot change exposure
settings after clicking the button.
When the progress bar reaches 100%, the
Confirm button turns into the Ready button.
Maximum Value
kVp kVp
99 14
