Ports and Cable Connections
1 2
No.
Emergency Stop Switch
1
2
3
4
5
6
7
8
Green X 12 TM (Model: PHT-75CHS) User Manual
5
4
3
Item
Port*
Door Lock Port
Exposure Switch Port
RS232 Port
Optic Port
Frame Ground Cable
Terminal
Power Cable
1. Imaging System Overview
6 7
Description
Connects the emergency stop switch to the
equipment.
Connects the door lock cable to the
equipment when installing a door lock.
Connects the exposure switch to the
equipment.
Used for testing and repairing the
equipment.
Connects the main MCU and the sensor
with the PC.
Connects the external FG with the internal
FG.
Connects the external power cable with the
internal power cable.
Supplies the power to the equipment.
*Emergency stop switch port is used in Russia only.
