6. How to Acquire CBCT Images
Check the capture location in the preview image. To change the location,
5.
follow the steps below:
1)
2)
3)
4)
94
Click the guideline (green lines) on the screen.
Drag the guideline to the desired location.
In the 8x5 mode, you can move the line up and down to set a new
capture location.
In the Endo mode, you can move the lines in all four directions (right,
left, up and down) to set a new capture location.
8x5 Mode Preview Image
Endo Mode Preview Image
