Insight PAN Mode
4.2.2
Green X 12 TM (Model: PHT-75CHS) User Manual
4. How to Acquire PANO Images
Insight PAN allows users to capture an image of the user-
selected area only. By capturing a specific area, this mode
minimizes the amount of radiation that the patient is
exposed to.
< Image Capture Area Selection window >
<Insight PAN image>
▪
When you want to capture a single tooth only, ensure
to select the teeth left and right in addition, to the teeth
you chose because each patient's arch is different.
▪
The minimum size of the areas that you capture with
the Insight PAN is 50 x 50 mm
▪
You can view the captured image with the Insight
PAN, using Insight NAVI. connected to EzDent-i
▪
Read the EzDent-i user manual to learn more
information about the Insight PAN.
2.
41
