Scout View
6.2.5
The Scout View option is available for 8x5 or Endo mode imaging. By selecting this
option, users can preview a Scout View image before performing a CT scan and adjust
the scan position as desired.
Please follow the steps below to perform the Scout View imaging.
Select 8x5 or Endo from the FOV menu.
1.
Select the exposure settings for the 8x5 or Endo mode.
2.
Position the patient according to the selected FOV. Once the patient
3.
positioning is completed, click Confirm.
When you see the message information window says, 'Do you want to
4.
proceed with SCOUT capturing?', click 'Yes'.
Green X 12 TM (Model: PHT-75CHS) User Manual
8x5
Please read 6.2.1 Normal CBCT or 6.2.4
Endo Mode, for instruction on how to select
exposure settings.
Please read 6.3.1 Other Capture Modes, for
instructions on how to align the patient's
position.
Click No if you want to skip the scout view
imaging.
If the patient moves during Scout mode
imaging, the capture location you selected
may become incorrect. Please guide the
patient to maintain their original position until
the end.
6. How to Acquire CBCT Images
Endo
