4. How to Acquire PANO Images

Normal Mode

4.2.1
Follow the steps below to select exposure settings for the Normal mode (normal
panoramic image).
Select Normal from the PANO Option.
1.
Select an Images Option.
2.
Select an arch type.
3.
Select a PANO examination option.
4.
38
Magic PAN is an image reconstruction algorithm, not a
scan option. For this reason, selecting Magic PAN does
not change the options and the menu on the console
software.
Mode
High Resolution
Green
Select Orthogonal from the menu to enable bitewing
options such as Bitewing Left.
Description
High-Resolution image
Normal-Resolution image
