6. How to Acquire CBCT Images

After the Image Acquisition

6.5
Follow the steps below after the image acquisition.
Use the temple support knob to open the temple supports.
1.
Guide the patient out of the X-ray room.
2.
Remove the sanitary vinyl cover from the bite block.
3.

Check the Acquired Image

6.6
Follow the steps below to check the acquired images.
Click Save to save the captured images. You can skip this step if you already
1.
select the Auto Save option before scanning.
102
The equipment returns to its initial position after capturing
the image. Ensure that the patient does not leave the
equipment until it stops moving.
Click Retake to capture another image.
How to Select the Auto Save Option
Select the Settings button on the console
1)
window.
Select User > Image Save option and check
2)
the box to apply the Auto Save.
Click Save.
3)
Green X 12 (Model: PHT-75CHS) User Manual
