Follow the steps below to select exposure settings for the console software.
Select a TMJ option on the PANO Examination menu.
1.
Select a patient type.
2.
Man
Select an X-ray intensity level.
3.
Hard
Category
(Age 12 or under)
(Above Age 12)
Green X 12 TM (Model: PHT-75CHS) User Manual
Women Child
Patient
Man
Males over the age of 12
Woman Females over the age of 12
Child Male or Female under the age of 12
Normal Soft
Average head
circumference
(cm)
Child
53±3
Adult
56±3
4. How to Acquire PANO Images
VATECH standard
Range (cm)
>53±3
53±3
<53±3
>56±3
56±3
<56±3
Intensity
level
Hard
Normal
Soft
Hard
Normal
Soft
