6. How to Acquire CBCT Images
Second Scan (Maxilla Scan)
Follow the steps below to position the patient for the second scan.
After the first scan is complete, ask the patient to exit the equipment.
1.
Click Confirm on the console window.
2.
After the first scan, the chinrest goes down. Guide the patient to open his or
3.
her mouth while the chin is placed on the chinrest.
▪
▪
▪
Adjust the patient's position according to the laser beam's location.
4.
▪
▪
▪
Follow the instructions in 6.4 Acquiring Images to complete the second
5.
(maxilla) scan.
100
After the first (mandible) scan, the system automatically
sets exposure settings for the second (maxilla) scan.
Grab handles with both hands and stand with your neck straight.
Place the chin on the chinrest.
Gently bite the bite block with front teeth.
The vertical beam must be aligned with the patient's mid-sagittal
plane. If necessary, center the patient's head.
The horizontal beam must be aligned with the patient's Frankfurt
plane. Use the chinrest up/down button to align the patient with the
beam.
Check if the shoulder beam touches the patient's shoulder. If
necessary, ask the patient to lower his or her shoulder.
Instruct the patient to exit only after the
equipment made a complete stop.
After clicking Confirm, the rotating unit will
spin, and both the chinrest and column will
move down for the maxilla scan.
Green X 12 (Model: PHT-75CHS) User Manual
