Accessories

1.7.4
The following accessories are used to position the patient and support the equipment.
The accessories that have contact with the patient must be disinfected between each
patient.
Accessory
Green X 12 TM (Model: PHT-75CHS) User Manual
Descriptions
Normal Bite
used for the PANO
-
(normal) and CBCT scan.
used for non-edentulous
-
patients.
Special Bite A
used for both edentulous
-
and non-edentulous
patients.
used for both TMJ and
-
sinus scanning.
Special Bite B
used for the PANO
-
(normal) and CBCT scan.
used for edentulous
-
patients.
Chinrest
used for all imaging
-
modes except the CEPH
mode.
Temple Supports (1 set)
Ear Rods (1 set)
Nasal Positioner Cover
- For CEPH
Carpus Plate
1. Imaging System Overview
Materials
PC (Polycarbonate)
PC (Polycarbonate)
PC (Polycarbonate)
ABS (Acrylonitrile butadiene
styrene) copolymer
Temple Supports:
PA(Polyamide)
Temple Support Pad: Silicone
Silicone
Silicone
PC (Polycarbonate)
21
