Ask the patient to enter the equipment and give the following instructions:
4.
▪
▪
▪
Adjust the patient's position according to the laser beam's location.
5.
The vertical beam must be aligned with the patient's mid-sagittal
▪
plane. If necessary, center the patient's head.
The horizontal beam must be aligned with the patient's Frankfurt
▪
plane. Use the chinrest up/down button to align the patient with the
beam.
▪ Check if the shoulder beam touches the patient's shoulder. If
necessary, ask the patient to lower his or her shoulder.
Ask the patient to place his or her tongue on the roof of the mouth and close
6.
eyes.
Turn the temple supports knob to close the temple supports to secure the
7.
patient's head.
Leave the X-ray room and follow the instructions in 6.4 Acquiring Images.
8.
Green X 12 TM (Model: PHT-75CHS) User Manual
Grab handles with both hands and stand straight.
Place the chin on the chinrest.
Gently bite on the bite block's groove with front teeth.
To prevent vision loss, ensure that the
patient's eyes do not meet the laser beam
during positioning
Review the patient's position before leaving
the X-ray room. If necessary, reposition the
patient.
6. How to Acquire CBCT Images
