5. How to Acquire CEPH Images (Optional)

Patient Positioning

5.3
Lateral / Full Lateral (Optional) Mode
5.3.1
Follow the steps below to position the patient for the lateral mode.
Remove all metal objects that the patient wears.
1.
Turn the nasal positioner to the Lateral / Full lateral mode marker.
2.
Use the column up/down button to adjust the equipment's height.
3.
Make a space between two ear rods for the patient's head.
4.
Ask the patient to stand straight under the CEPH unit.
5.
Slid the ear rods until their tips gently touch the patient's outer ear canals.
6.
64
Metal objects can cause ghosts or shadows on
the X-ray image and lower the image quality.
Ensure that the patient does not collide with the
equipment while in motion.
DO NOT slide ear rods until adjusting the
equipment's height is finished.
Green X 12 (Model: PHT-75CHS) User Manual
