Once the X-ray intensity level is selected, the system automatically sets the
7.
exposure condition. To change the condition. Click the plus-minus button next
to the voltage and the current symbols.
Each time you click the button, the voltage changes by ± 1.0 kVp, and the
current by ± 1.0 mA.
The table below shows the range of exposure conditions that you can adjust.
Mode
Lateral
Others
Click Confirm. After clicking the button.
8.
•
DAP (Dose Area Product), scan, and exposure time are displayed on the
scan information window.
Guide the patient to the X-ray room when you see the message below.
9.
Green X 12 TM (Model: PHT-75CHS) User Manual
5. How to Acquire CEPH Images (Optional)
Minimum values
kVp mA
60 4
60 4
DO NOT click Confirm unless your selections for
exposure settings are final. You cannot change
settings after Confirm is clicked.
When the progress bar reaches 100%, Confirm turns
into Ready.
Maximum Values
kVp mA
99 15
99 14
