Double Scan Mode
6.2.2
In Double Scan mode, the mandible (lower jaw) is first scanned followed by the maxilla
(upper jaw). However, exposure settings need to be set only once. After the first (lower
jaw) scan is complete, the system automatically sets the condition for the second (upper
jaw) scan.
Follow the steps below to set exposure settings for Double Scan mode.
Select Double Scan from the FOV menu. Once selected, the system will
1.
automatically set the vertical option (Mandible) and the horizontal option
(Center).
Check 'Auto Pano' box if you also want to acquire a panoramic image at the
2.
end of the scan.
Select an image option.
3.
High Resolution
Select a voxel size.
4.
Green X 12 TM (Model: PHT-75CHS) User Manual
For the second scan, the vertical option
'Maxilla' is selected for second scan.
Mode Description
High-Resolution image
Green Normal-Resolution image
6. How to Acquire CBCT Images
83
