Click Confirm. After clicking the button:
7.
▪ The rotating unit moves to the scanning position.
▪ Laser beams are turned on.
▪ The progress bar appears above the Confirm button.
▪ The scan information window shows the estimated DAP (Dose Area
Product), scan time, and exposure time.
Guide the patient to the X-ray room when you see the message below.
8.
Green X 12 TM (Model: PHT-75CHS) User Manual
4. How to Acquire PANO Images
DO NOT click Confirm unless your selections
are final. You cannot change exposure
settings after clicking the button.
When the progress bar reaches 100%, the
Confirm button turns into the Ready button.
45
