5. How to Acquire CEPH Images (Optional)
Carpus Mode
5.3.5
Follow the steps below to position the patient for the carpus mode:
Remove all metal objects that the patient wears.
1.
Turn the nasal positioner and fold it up.
2.
Ask the patient to place his or her right-hand on the carpus plate. Ensure that
3.
all five fingers are fully stretched out and the patient's palm lies flat on the
plate.
Give the patient the following instructions:
4.
Instruct the patient to:
5.
▪
▪
Leave the X-ray room and follow the instructions in 5.4 Acquiring Images.
6.
72
Ensure that the carpus plate is installed and secured before
positioning the patient.
Metal objects can cause ghosts or shadows on
the X-ray image and lower the image quality.
Stay in the same position.
Close his or her eyes.
Review the patient's position before leaving the X-
ray room. If necessary, reposition the patient.
Green X 12 (Model: PHT-75CHS) User Manual
