In Basic mode, once the condition of recurrence is detected the pump stops and awaits manual reset. This condition is communicated to the user
by the lighting of the red "Alarm" LED and the appearance of the word "ANTICYCLING" on the display. After the leak has been removed, you can
manually force restart by simultaneously pressing and releasing the "˄" and "˅" keys.
In Smart mode, once the leak condition is detected, the parameter RP is increased to decrease the number of starts over time.
6.1.3 - Anti-Freeze (Protection against freezing of water in the system)
The change of state of water from liquid to solid involves an increase in volume. It is therefore essential to ensure that the system does not remain
full of water with temperatures close to freezing point, to avoid breakages of the system. This is the reason why it is recommended to empty any
electropump that is going to remain unused during the winter. However, this system has a protection that prevents ice formation inside by activating
the electropump when the temperature falls to values close to freezing point. In this way the water inside is heated and freezing prevented.
The Anti-Freeze protection only works if the system is electrically powered: if the plug is disconnected or in the absence of
current the protection cannot work.
However, it is advised not to leave the system full during long periods of inactivity: drain the system properly through the drainage cap and put it
away in a sheltered place.
6.1.4 - "BP1" Blockage due to fault of the delivery pressure sensor (system pressurisation)
If the device detects a fault in the delivery pressure sensor the pump remains blocked and the error signal "BP1" is given. This status begins as
soon as the problem is detected and ends automatically when correct conditions have been restored.
6.1.5 - "BP2" Blockage due to fault of the suction pressure sensor
Present only in models with KIWA function.
If the device detects a fault in the suction pressure sensor the pump remains blocked and the error signal "BP2" is given. This status begins as
soon as the problem is detected and ends automatically when correct conditions have been restored.
6.1.6 - "PB" Blockage due to supply voltage outside specifications
This occurs when the allowed line voltage at the supply terminal assumes values outside the specifications. It is reset only automatically when the
voltage at the terminal returns within the allowed values.
6.1.7 - "SC" Blockage due to short circuit between the motor phases
The device is provided with protection against the direct short circuit which may occur between the motor phases. When this blockage is indicated
you can attempt to restore operation by simultaneously holding down the ˄ and ˅ keys, but this will not have any effect until 10 seconds have
passed since the moment the short circuit occurred.
6.2 - Manual reset of error conditions
In error status, the user can cancel the error by forcing a new attempt, pressing and then releasing the ˄ and ˅ keys.
6.3 - Self-reset of error conditions
For some malfunctions and blockage conditions, the system attempts automatic self-reset.
The auto self-reset procedure concerns in particular:
"BL" Blockage due to water lack
"PB" Blockage due to line voltage outside specifications
"OT" Blockage due to overheating of the power stages
"HL" Blockage due to too high liquid temperature
For example, if the system is blocked due to water lack, the device automatically starts a test procedure to check whether the machine is really
left definitively and permanently dry. If during the sequence of operations an attempted reset is successful (for example, the water comes back),
the procedure is interrupted and normal operation is resumed.
Table 13 shows the sequences of the operations performed by the device for the different types of blockage..
Display
indication
BL Blockage due to water lack
Blockage due to line voltage
PB
(2)
outside specifications
Blockage due to overheating of
OT
the power stages
(2) Applicable to firmware versions ≤ 4.x.x
Parameters available in version KIWA
(2) Applicable to firmware versions ≤ 4.x.x
Automatic resets of error conditions
Description
-
-
-
-
-
ENGLISH
"OC" Blockage due to motor overload
"BP1" Blockage due to fault of the pressure sensor
(2)
"BP2" Blockage due to fault of the Kiwa pressure sensor
Automatic reset sequence
One attempt every 10 minutes for a total of 6 attempts.
One attempt every hour for a total of 24 attempts
One attempt every 24 hours for a total of 30 attempts.
It is reset when it returns to a specific voltage.
It is reset when the temperature of the power stages returns within the
specifications.
62
