5.4 - Manual Menu
In manual operation, the sum of the input pressure and the maximum pressure that can be supplied must not be greater than 6 bar
/ 87 psi.
From the main menu, hold down simultaneously the "SET" and "˄" and "˅" keys until the manual menu page appears (or use the selection menu
pressing "˄" or "˅"). Press SET to leave this menu and return to the main menu. Entering the manual menu by pressing the SET "˄" "˅" keys
puts the machine into forced STOP condition. This function can be used to force the machine to stop. In the main menu, irrespective of the
parameter displayed, it is always possible to perform the following controls:
Temporary starting of the electropump.
Pressing the MODE and "˄" keys at the same time causes the pump to start at speed RI and this running status remains as long as the two keys
are held down. When the pump ON of pump OFF command is given, a communication appears on the display.
Starting the pump
Holding down the MODE "˅" "˄" keys simultaneously for 2 sec. causes the pump to start at speed RI. The running status remains until the SET
key is pressed. The next time the SET key is pressed the pump leaves the manual menu. When the pump ON of pump OFF command is given,
a communication appears on the display. In case of operation in this mode for more than 5 minutes with no flow of liquid, an overheating alarm
will be triggered, with the error PH shown on the display. Once the PH error condition is no longer present, the alarm will be reset automatically.
The reset time is 15 minutes; if the PH error occurs more than 6 times consecutively, the reset time increases to 1h. If the error still persists, the
pump will remain in stop status until the user restarts it using the "MODE" "˅" "˄" keys.
5.4.1 - Status
Displays the pump status.
5.4.2 - RI: Speed setting
Sets the motor speed in rpm. Allows you to force the number of revolutions at a predetermined value.
5.4.3 - VP: Pressure display
Plant pressure measured in [bar] or [psi] depending on the measuring system used.
5.4.4 - VF: Flow display
Displays the flow in the chosen unit of measure. The measuring unit may be [l/min] o [gal/min] see par. 5.5.3 - MS: Measuring system. If the recorded
measurement is below the sensitivity threshold of the flow sensor, the measurement value flashes next to the VF identification.
5.4.5 - PO: Absorbed power display
Power absorbed by the electropump in [kW].
If the maximum allowed power is exceeded, the measurement flashes next to the PO identification.
5.4.6 - C1: Phase current display
Motor phase current in [A].
If the maximum allowed current is exceeded, the identification C1 blinks, indicating an imminent tripping of the overload protection.
5.4.7 - RS: Rotation speed display
Motor rotation speed in rpm.
: Supply voltage
5.4.8 - SV
Present only in some models.
5.4.9 - SR : Supply range
Present only in some models.
Indicates the range of supply voltage found. It may have the values: [110-127] V or [220-240] V. If the range is not determined, it has the value "- -".
5.4.10 - TE: Dissipator temperature display
Shows the value of the heatsink temperature.
5.5 - Installer Menu
From the main menu, hold down simultaneously the "MODE" and "SET" and "˅" keys until the first parameter of the installer menu appears on the
display (or use the selection menu pressing ˄ or ˅). The menu allows you to view and modify various configuration parameters: the MODE key
Parameters available only in the DUAL VOLTAGE version (supply voltage 230 V / 115 V)
