DETACHING AND ATTACHING THE OVEN DOOR

For cleaning purposes and to remove the door panels, you can detach the oven door.
Every door hinge has a locking rod, when it is close, door was fixed in place, then the
door was not disassembly. If in order to remove down door to open the locking rod,
hinge will be locked and would not bite.
When the hinge not locked, it will have a big strength to close in sudden. Make sure
that the locking rod is closed all the time, and insure it was open when remove the
door.
Remove the door
• Fully open the door
• Fold up the right and left side of locking rod. (picture A)
• Close the door until reach to stop step, hold on both
left and right sides of the door, then reclose the door,
upward and downward and pull out the door.
Install the oven door
Disassemble the door in reverse order.
• When installing the oven door, make sure both hinge
plug into opening mouth directly.
• Both sides of hinge rabbet must bite up each other.
• When open the door, spread down locking rod (picture B)
• If the door drop accidently or hinges shut up suddenly,
do not push you hand in hinges. Please call your after-sell
department.
Remove and install door glass
Removal
• Remove oven door, put it on a piece of cloth.
• Using two index fingers to push the button of the door
inner glass bracket,The bracket will eject automatic
• Take away the inner glass and middle glass.
