This section provides a comprehensive installation and operation guide which will assist
with the commissioning of the 8045 Flow Transmitter.

2.1 INSTALLATION

See section 6.4
See section 3.1
See section 3.4
See
section 3.3.1

QUICKSTART

Unpacking
Order
code OK?
O.K
Install the fitting
on the piping
Unscrew the 4 screws
and open
Connect power
supply cable
Connect output
cable
Re-assemble the unit
and install onto the fitting
Connect the earth to
the earthing screw
Turn on the power
Check
display is 0
with no flow
Yes
Enter the K-Factor
Program the Transmitter
4
Verification of items received.
See section 6.4
No
Contact your local Bürkert
subsidiary
Ensure the power
supply is disconnected
before starting work.
Ensure that security provisions
are considered with the power
cable and relay circuit.
Pay attention to the
max.permitted load of
the output current loop.
The sensor finger must be immer-
sed in fluid 24 hours before cali-
bration (section 4.5.3)
Immerse the transmit-
ter into the fluid and
perform a „flow zero"
No
point calibration.
See section 4.4.3
See the next page.
