Quickstart; Installation - bürkert 8045 Bedienungsanleitung

This section provides a comprehensive installation and operation guide which will assist
with the commissioning of the 8045 Flow Transmitter.
2.1

INSTALLATION

See section 6.4
See section 3.1
See section 3.4
See
section 3.3.1

QUICKSTART

Unpacking
Verify
Order code
O.K
Install the fitting
on the piping
Unscrew the 4
screws and open
Connect power
supply cable
Connect output
cable
Re-assemble the unit
and install onto the
fitting
Connect the earth to
the earthing screw
Turn on the
power
Check
display is 0
with no flow
Yes
Enter the
K-Factor
Program the Transmitter
Verification of items received.
See section 6.4
Contact your local Bürkert
No
subsidiary
Ensure the power supply
is disconnected before
starting work.
Ensure that security provisions
are considered with the
power cable and relay circuit.
Pay attention to the max.
permitted load of
the output current
loop.
The sensor finger must be
immersed in fluid 24 hours
before calibration (section 4.5.3)
Immerse the transmitter
No
into the fluid and perform
a „flow zero" point
calibration
See section 4.4.3
See the next page.
