6.1 SPECIFICATIONS

Specification in relation to the process
Flow measurement
Measurement type
Measuring range
Measuring error
Linearity
Repeatability
(*) Under reference conditions i.e measuring fluid = water, ambient and water temperatures
of 20 °C, applying the minimum inlet and outlet pipes straights, matched inside pipe dimen-
sions
o. R. = of Reading
o. F.S. = of Full Scale (10 m/s)
Piping installation
Fitting
Pressure rating
with a PVDF sensor
with a st. steel sensor
Fluid temperature
with a PVDF sensor
with a st. steel sensor
Leitfähigkeit des Mediums
Materials contacting the fluid
Sensor armature
Electrodes
Earth ring
(version with PVDF sensor)
Seals
Electrode armature
(version with st. steel sensor) PEEK
Specificaton in relation to the control outputs
Electrical connection
Power supply
Consumption
SPECIFICATIONS
Electromagnetical measurement
0,2-10 m/s
1) with individual works calibration (on request) or
Teach-In: +/- 2 % o. R. (1-10 m/s) (*)
2) with standard mean K-Factor:
+/- 4 % o. R. (1-10 m/s) (*)
+/- (1 % o. R. + 0,1% o.F.S.) (*)
0,25 % of measured value
Stainless steel, brass or plastic (PVDF, PP, PVC)
Solvent/fusion spigots, threaded ports (G, NPT, Rc),
buttwelding ends, flange, Tri-clamp
see instruction manual S020
PN 10
PN 16
0 to 80 °C
-15 to 110 °C
min. 20 μS/cm
PVDF oder Edelstahl 316L (DIN 1.4404)
Edelstahl 316L (DIN 1.4404)
Edelstahl 316L (DIN 1.4404)
FKM (standard)
18-36 VDC, filtered and regulated
(oscillation rate +/- 5%)
300 mA max.
36
8045
