Trip Amplifier 1/209
Handling with a PC
6.6 Action 6 – Check Edited Programs
<ALT><R>
NAME.209
<ALT><L>
<F5>
<F4>
Alterations should be saved as explained in action 5.
6.7 Action 7 – Edit a Program
This task will not have to be undertaken very often. You should have prior programming
experience before attempting it.
<F2>
NAME.EDT
6.8 Action 8 – Ending a Job
1/209
1/209
94
Load parameters from file.
Enter the desired file name or
load parameters from the trip amplifier.
Data are now accessible.
Check the program. Changes can now be made immediately.
Use the tabulator <TAB> key to move to the programming step
which is to be altered and overwrite with the new command.
Check constants. Changes can now be made immediately.
Use the tabulator <TAB> key to move to the constant which is
to be altered and overwrite with the new value.
Call the editor.
Enter the name of the FILE to be edited. Existing programs
can be altered using the editor or new programs can be
established. <F1> offers extensive HELP during an EDIT
session. Program examples are to be found in the DEMO
directory under DEMOE.EDT ... or in directory STD under
STD_1.EDT ... STD_8.EDT.
Comments must be preceded by ";".
Once a program has been established it must pass the
compiler. Only then will you have an executable program
which can be transferred to the trip amp using action 5.
Remove the connector cable from the PCs serial data link.
Place jumper MODE in position 3-10 (RUN).
