Trip Amplifier 1/209
Technical Data
Transfer characteristics
Temperature influence
Indicators/settings
Display elements
Configuration
Directive conformity
Electromagnetic compatibility
Directive 2004/108/EC
Conformity
Protection degree
Ambient conditions
Ambient temperature
Storage temperature
Relative humidity
Mechanical specifications
Mass
Dimensions
Construction type
56
< 0.1 % / 10 K
LED 1: trip value 1
LED 2: trip value 2
LED 3: trip value 3
LED 4: trip value 4
LED green: Power on
via RS 485 interface at the front side
The device has been used for the same applications
for several years. It therefore features an appropriate
electromagnetic field immunity in accordance with
EN 61326-1:2006. The device must not be used in
new plants.
IEC 60529
-10 ... 60 °C (14 ... 140 °F)
-25 ... 80 °C (-13 ... 176 °F)
< 75 % (annual mean)
< 95 % (30 d/year), no moisture condensation
300 g
22 x 143 x 193 mm (0.9 x 5.6 x 7.6 in)
Eurocard 100 x 160 mm (3.9 x 6.3 in) acc. to
DIN 41494, front panel 4TE, mountable in 19" rack
