Software Description
Connect the trip amplifier via a serial data link (RS 232) to the personal computer. The
desired COM port is assigned during start-up (/2 = COM2) as shown above. The port may
be changed under MENU support using (<ALT><C>). Only lines GND (7), TXD (2) and
RXD (3) of the PC need to be connected with the trip amplifier. A suitable cable is
available as an accessory.
The following START-up parameters are possible:
/g
/e
/0
/1
/2
Start options marked by a star * will be assumed unless other parameters are used.
Menu items are explained via HELP text. Use key <F1> for HELP. Context sensitive HELP
texts simplify matters when working with the program. Every line of the menu can thus be
explained in detail. HELP is also accessible using alphabetical search.
4.9

Extended User Interface Version V4.00

After the program start, the main menu gives you the version N° of your user menu. The
following points of the user menu of the trip amplifiers type 1/209 have been extended:
1. Apart from setting the parameters, the standard programs of the user window F6 can
now also be used for rereading the set values from existing trip amplifers. For that
purpose, the new user menu automatically writes a program identification number into
the standard program which you configurate with F6. While memorizing, that
identication N° will be transmitted to the trip amplifier. By means of that identification
N°, the user menu will find the assignment of the parameters to the user window while
rewriting the standard program (Applies to standard programs only).
2. When storing an EDITOR processed program, it is now possible to assign a new file
name so that the source file remains unchanged.
3. A data transfer with the interface cable is now also possible with fast PENTIUM
computers.
The new software is compatible with all units in operation. It should, however, be observed
that the comfortable rewrite function with the standard menu F6 can only be used on such
apparatus on which the standard program has been stored in the unit with the new
software. That applies to all type 1/209 trip amplifiers delivered as from March 1st, 1997.
In case you wish to use that function for older units, you should repeat storing your
existing standard program in the unit with the new software by means of F6.
90
German help *
English help
DEMO mode active *
Serial link via COM1
Serial link via COM2
