Test Parameters - Pepperl+Fuchs 1/209 Handbuch

Trip Amplifier 1/209
Software Description
4.5.1

Test Parameters

Test parameters are used for electrical device checks.
Analogue inputs, switches ans push buttons (online):
P711
P712
P713
P714
P721
P722
P723
P724
P731
P732
P733
P741
P742
P743
P744
Check relay / solid state output (offline):
Jumper MODE = ENABLE (interrupts trip monitoring function)
P751 = 1
P752 = 1
P753 = 1
P754 = 1
Check digital output (offline):
Jumper MODE = ENABLE (interrupts trip monitoring function)
P761 = 1
P762 = 1
P763 = 1
P764 = 1
Check LEDs (offline):
Jumper MODE = ENABLE (interrupts trip monitoring function)
P771 = 1
P772 = 1
P773 = 1
P774 = 1
P775 = 1
Check calibration data (online):
See sections "Testing Relay Outputs", "Testing Digital Outputs", "Testing LEDs" and
"Calibration".
P781
P782
P783
P784
82
analogue input 1 corresponding to 0 ... 1 (read)
analogue input 2 corresponding to 0 ... 1 (read)
analogue input 3 corresponding to 0 ... 1 (read)
analogue input 4 corresponding to 0 ... 1 (read)
digital input 1 corresponding to 0 or 1 (read)
digital input 2 corresponding to 0 or 1 (read)
digital input 3 corresponding to 0 or 1 (read)
digital input 4 corresponding to 0 or 1 (read)
pugh button 1 corresponding to 0 or 1 (read)
push button 2 corresponding to 0 or 1 (read)
pugh button 3 corresponding to 0 or 1 (read)
DIP switch 1 corresponding to 0 or 1 (read)
DIP switch 2 corresponding to 0 or 1 (read)
DIP switch 3 corresponding to 0 or 1 (read)
DIP switch 4 corresponding to 0 or 1 (read)
activate relay 1 (P751 = 0 relay 1 deenergized)
activate relay 2 (P752 = 0 relay 2 deenergized)
activate relay 3 (P753 = 0 relay 3 deenergized)
activate relay 4 (P754 = 0 relay 4 deenergized)
digital output 1 on (P761 = 0 digital output 1 off)
digital output 2 on (P762 = 0 digital output 2 off)
digital output 3 on (P763 = 0 digital output 3 off)
digital output 4 on (P764 = 0 digital output 4 off)
LED 1 on (P771 = 0 LED 1 off)
LED 2 on (P772 = 0 LED 2 off)
LED 3 on (P773 = 0 LED 3 off)
LED 4 on (P774 = 0 LED 4 off)
LED 5 on (P775 = 0 LED 5 off)
check calibration of analogue input 1 (read)
check calibration of analogue input 2 (read)
check calibration of analogue input 3 (read)
check calibration of analogue input 4 (read)
