Trip Amplifier 1/209
Software Description
Programming the example
Set the jumper MODE to ENABLE so that the unit can be programmed.
Program the parameters using a terminal as follows. A personal computer will offer a more
user friendly approach. An EDITOR can be used to write programs.
• P801=0 <Enter> ; constant K1
• P802=100 <Enter> ; constant K2
• P803=30 <Enter> ; constant K3
• P804=70 <Enter> ; constant K4
• P805=1 <Enter> ; constant K5
Enter the program
• P100=DSP
• P101=X01
• P102=Z00
• P103=E
• P104=0
• P105=1
• P106=DSP
• P107=K03
• P108=202
• P109=L
• P110=0
• P111=L
• P112=DSP
• P113=K04
• P114=Z02
• P115=H
• P116=0
• P117=1
• P118=DSP
• P119=K05
• P120=Z03
• P121=X
• P122=0
• P123=1
• P124=CLI
• P125=AE1
• P126=K01
• P127=K02
• P128=X01
• P129=ALM
• P130=X01
86
beginning of range for temp.
scale value for temp.
low trip
high trip
hysteresis
input 1
low trip
high trip
hysteresis
live zero input
low trip
