Trip Amplifier 1/209
Handling with a PC
6.4 Action 4 – Edit Standard Programs
<F6>
1 <ENTER>
zero
full scale
display
display mode
input zero
trip point
hysteresis
display
display mode
relay action
switch at
contact
Changes become valid once you have accepted entries by pressing 0 = OK or select OK
via the <TAB> key (will be highlighted) followed by <ENTER>. Abort using <ESC>.
6.5 Action 5 – Save and Send Programs
<ALT><W>
NAME.209
<ALT><S>
Call a standard program.
Select the desired program number 1 (example 1). A window will
be opened for user entries (<F1> HELP).
0 Use <TAB> key to move forward.
100 Towards entry fields.
E01 Use <SHIFT-TAB> to move backwards.
2
( ) live Change using arrow keys.
( ) dead Change using arrow keys.
50
1
L01
2
( ) OFF Change using arrow keys.
( ) ON Change using arrow keys.
( ) set Change using arrow keys.
( ) hyst Change using arrow keys.
( ) LOW Change using arrow keys.
( ) HIGH Change using arrow keys.
( ) Line - toggle using space key (X = active).
Save data on file. This is to establish a back-up copy of a
standard copy after effecting changes. The copy can later be
used to configure spares or new devices (see <ALT><S>).
However the changes cannot be displayed in the same menu
supported way as the original standard setting.
Type the desired name and press <ENTER>. If you want to
create several identical devices, repeat above action from
<ALT><W> and issue a file name per device (TAG N°).
Save data in the trip amplifier. If you want to create several
identical devices, connect them to your personal computer one
by one and save data with <ALT><S>.
93
